DC Characteristics

Flash Loader Utility

Mounting the Module

UM013904-0203
Downloaded from Elcodis.com electronic components distributor
As different combinations of application modules are loaded onto the
®
eZ80 Development Platform, current requirements change. Please see
Table 24 on page 41 to reference current consumption values for these
different module combinations.
A 0.1-Farad capacitor is provided on the eZ80F92 Flash Module as a
short-term battery backup for the RTC (see the
page 59). The part number of the capacitor made by Panasonic is
EECS0HDV. The capacitor is connected to RTC_VDD to provide power
to the RTC when main power to the chip is removed; it is also connected
to the 3.3V supply to the chip for recharging. The RTC can operate down
to 3.0V; it requires 10µA of current. The (keep alive) time this capacitor
can supply power to the RTC, from 3.3V to 3.0V, is approximately 3000
seconds, or 50 minutes.
The Flash Loader utility allows the user a convenient way to program on-
chip Flash memory. Please refer to the
User Guide (PUG0016) for more details.
When mounting the eZ80F92 Flash Module onto the eZ80
Platform, check its orientation to the platform to ensure a correct fit. Pin 1
®
of JP1 on the eZ80 Development Platform must align with pin 1 of JP1
®
on the eZ80 Development Platform; Pin 1 of JP2 on the eZ80F92 Flash
Module must align with pin 1 of JP2 on the eZ80
form, etc.
PRELIMINARY
eZ80F92 Development Kit
User Manual
Schematic Diagrams
External Flash Loader Product
®
Development
®
Development Plat-
DC Characteristics
