ZiLOG S3F8S19 User Manual

S3 family of microcontrollers development kit

Advertisement

Quick Links

S3 Family of Microcontrollers
S3F8S19 Development
Kit
User Manual
UM026803-0816
®
Copyright ©2016 Zilog
, Inc. All rights reserved.
www.zilog.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the S3F8S19 and is the answer not in the manual?

Questions and answers

Summary of Contents for ZiLOG S3F8S19

  • Page 1 S3 Family of Microcontrollers S3F8S19 Development User Manual UM026803-0816 ® Copyright ©2016 Zilog , Inc. All rights reserved. www.zilog.com...
  • Page 2 HEREIN OR OTHERWISE. The information contained within this document has been verified according to the general principles of electrical and mechanical engineering. S3 and Z8 are trademarks or registered trademarks of Zilog, Inc. All other product or service names are the property of their respective owners.
  • Page 3 S3F8S19 Development Kit User Manual Revision History Each instance in this document’s revision history reflects a change from its previous edi- tion. To learn more, refer to the corresponding page(s) or appropriate links furnished in the table below. Revision Date...
  • Page 4 S3 PGM connector to connect the Board to a host development PC using the S3 Flash In-System Programmer II (ISP). To learn more about the S3F8S19 MCU, refer to the S3F8S19 Product Specification (PS0312) and/or the S3 Flash In-System Programmer User Manual (UM0266).
  • Page 5 The S3F8S19 Development Kit includes the following key items. • S3F8S19 Development Board, which contains the following features: S3F8S19 48-pin QFP MCU operating at 12 MHz, with 32 KB of internal Flash – memory and 2 KB of internal RAM memory USB interface to supply power to the board and used as a PC virtual COM port –...
  • Page 6 ZDS II – S3_<version>.exe, and follow the on-screen instruc- tions. Establish a Connection with the PC Observe the following procedure to connect the S3 Flash ISP II and S3F8S19 Develop- ment Board to your PC. Caution: Disconnect or turn off the power to the S3F8S19 Development Board before connecting or disconnecting the S3 Flash ISP II.
  • Page 7 S3F8S19 Development Kit User Manual Figure 2. Connecting the S3 Flash ISP II to the Development PC 2. Connect the 10p 5x2 ribbon cable to the S3 Flash ISP II, as shown in Figure 3. Figure 3. Connecting the 10-pin Ribbon Cable to the S3 Flash ISP II 3.
  • Page 8 Caution: damage to the S3 Flash ISP II. 4. With the USB A (male) to Mini-B cable, connect Port P1 on the S3F8S19 Develop- ment Board to a USB port on the Development PC to apply power to the Development Board, as indicated in Figure 5.
  • Page 9 Figure 6. The Completed ISP II and Development Board Assembly Start the S3F8S19 Ledblink Sample Program The S3F8S19 Development Kit includes a sample program that demonstrates an LED blinking application. To start the S3F8S19 Ledblink sample program, observe the follow- ing procedure.
  • Page 10 Figure 8 and click . A list of source files will appear in the Work- Open space panel. Figure 8. Select the ledblink.zdsproj Project UM026803-0816 Start the S3F8S19 Ledblink Sample Program...
  • Page 11 7. On the Debugger page, select from the Target list, then select S3F8S1X_FlashIspII from the drop-down menu, as indicated in Figure 9. S3FlashIspII Debug Tool Figure 9. Select the Target and Debug Tool UM026803-0816 Start the S3F8S19 Ledblink Sample Program...
  • Page 12 0 warning(s) 0 error(s) Build succeeded Note: This Output Checksum message is an example and may not match the actual checksum of the project for a particular release of the ZDS installation software. UM026803-0816 Start the S3F8S19 Ledblink Sample Program...
  • Page 13 Figure 11. As a result, LEDs D2, D3, and D4 will blink in sequence. Figure 11. Select Reset+ Go from the Debug Menu Trouble Shooting Tips The following trouble-shooting tips are useful when starting the S3F8S19 Ledblink sam- ple program. •...
  • Page 14 User Manual S3F8S19 Development Board The purpose of the S3F8S19 Development Kit is to provide a set of hardware and software tools for the development of hardware and firmware for applications based on the S3F8S19 microcontroller. An image of the S3F8S19 Development Board is shown in Figure 12;...
  • Page 15 S3F8S19 Development Kit User Manual Operations and Power Options The operations and power options of the S3F8S19 Development Board are listed in Table 1. Table 1. Operations and Power Options of the S3F8S19 Development Board Option Operations Jumper Status Power...
  • Page 16 ISP-related option selectable (ROM address 3EH) via Smart Option • Oscillator selection, LVR selection (ROM address 3FH) via Smart Option To learn more about the S3F8S19 MCU, refer to the S3F8S19/S3F8S15 Product Specifi- cation (PS0312). Magnetic Buzzer The CEM1206S magnetic buzzer (U2) manufactured by CUI Inc. is rated at a frequency –...
  • Page 17 Reset Circuit The reset circuit features a 100 KΩ pull-up resistor R6 and SW1. This circuit resets the S3F8S19 MCU when SW1 is pressed. See Figure 15 for a representation of the reset cir- cuit. Figure 15. The Reset Circuit...
  • Page 18 S3F8S19 Development Kit User Manual The VIM-404-DP-RC-S-HV LCD manufactured by Varitronix Ltd. is a 20-pin module seated on both J4 and J5. Figure 17 shows an image of this LCD. Figure 17. LCD This four-digit LCD is activated by selecting the segment of each digit that must light up.
  • Page 19 A Flash Loader utility is included in Zilog Developer Studio II via the Tools menu. Figure 19 shows an image of the Flash Programming screen. Figure 19. The Flash Loader Programming Screen You can program the S3F8S19 MCU directly using the hex code generated from the ZDS IDE tools. UM026803-0816...
  • Page 20 User Manual S3F8S19 Development Kit Documentation The documents associated with the S3F8S19 Development Kit are listed in Table 2. Each of these documents can be obtained from the Zilog website by clicking the link associated with its Document Number. Alternatively, navigate to the directory listed in the Location column in your installed application.
  • Page 21 S3F8S19 Development Kit User Manual Appendix A. Schematic Diagrams Figures 20 and 21 present schematic diagrams of the S3F8S19 Development Board. Figure 20. S3F8S19 Development Board Schematic Diagram, #1 of 2 UM026803-0816...
  • Page 22 S3F8S19 Development Kit User Manual Figure 21. S3F8S19 Development Board Schematic Diagram, #2 of 2 UM026803-0816...
  • Page 23 User Manual Customer Support To share comments, get your technical questions answered, or report issues you may be experiencing with our products, please visit Zilog’s Technical Support page at http:/ support.zilog.com. To learn more about this product, find additional documentation, or to discover other fac-...
