ZiLOG eZ80F91 Quick Start Manual

Modular development kit
Hide thumbs Also See for eZ80F91:

Advertisement

Quick Links

Download this manual See also: User Manual
Introduction
This Quick Start Guide provides instructions and configuration information for ZiLOG's
eZ80F91 Mini Ethernet module, eZ80Acclaim!
components. The eZ80F910100KIT and eZ80F910200KITG modular development kits
are covered in this guide.
Kit Contents
For a complete list of material shipped with the eZ80F91 Modular Development Kit
(eZ80F910200KITG), refer to eZ80F91 Series Development Kit Packing List (PAK0015).
System Requirements
Table 1
lists the system requirements for running ZDS II.
Table 1. ZDS II System Requirements
Recommended Configuration
• PC running MS Windows XP
Professional
• Pentium III/500 MHz or higher processor
• 128 MB RAM
• 110 MB hard disk space
• Super VGA video adapter
• CD-ROM drive
• One or more RS-232 communications
ports
• USB high-speed port
Installation Overview
The eZ80F91 Mini Ethernet module is preinstalled on the eZ80Acclaim! MDS adapter
board. To set up the development kit, you must install the ZDS II software, connect the kit
eZ80F91 Modular
Development Kit
Quick Start Guide
Copyright © 2007 by ZiLOG, Inc. All rights reserved.
www.zilog.com
®
MDS adapter board, and associated
Minimum Configuration
• PC running MS Windows 98SE/
Win2000–SP4/WinXP Professional
• Pentium II/233 MHz processor
• 96 MB RAM
• 25 MB hard disk space (documentation
not installed)
• Super VGA video adapter
• CD-ROM drive
• One or more RS-232 communications
ports
• USB high-speed port
QS004609-0707

Advertisement

loading
Need help?

Need help?

Do you have a question about the eZ80F91 and is the answer not in the manual?

Questions and answers

Related Manuals for ZiLOG eZ80F91

Summary of Contents for ZiLOG eZ80F91

  • Page 1 The eZ80F910100KIT and eZ80F910200KITG modular development kits are covered in this guide. Kit Contents For a complete list of material shipped with the eZ80F91 Modular Development Kit (eZ80F910200KITG), refer to eZ80F91 Series Development Kit Packing List (PAK0015). System Requirements Table 1 lists the system requirements for running ZDS II.
  • Page 2 4. Connect the development kit to your PC and run the supplied sample project as described in Running Sample Projects on page 6. For complete details on developing an application for the development kit, refer to ZiLOG Developer Studio—eZ80Acclaim! User Manual (UM0144) and eZ80F91 Modular Devel- opment Kit User Manual (UM0170). QS004609-0707...

  • Page 3: Installing The Usb Smart Cable

    Modular Development Kit Install the ZDS II Software and Kit Documentation Follow the steps below to install ZDS II and the eZ80F91 development kit documentation: 1. Insert the ZDS II CD into your computer’s CD-ROM drive. DemoShield launches automatically. If DemoShield does not launch automatically, open the Windows...
  • Page 4 Modular Development Kit <ZDS II Installation Directory>\device drivers\USB <ZDS II Installation CD>\Device Drivers\USB The Windows Security dialog box is displayed. 6. Select Install this driver software anyway. 7. When the software has been installed, click Closed. For Windows XP 1.
  • Page 5 Modular Development Kit For Windows 98SE 1. Connect the USB Smart Cable to the host PC. The Found New Hardware Wizard should activate automatically. 2. In the Wizard, click Next. 3. Select Search for the best driver for your device (Recommended); then click Next.
  • Page 6 A sample starter program is provided on the ZDS II CD-ROM. It is demonstrates how to write proper code for the eZ80F91 modular development kit. The program writes a few character strings either to RS232 PortP2 on the eZ80Acclaim! MDS adapter board or (when running the Simulator Debug Tool) to the Simulated UART Output window.
  • Page 7 Flow control: None 8. Click OK. HyperTerminal connects to your kit. 9. Launch ZDS II by navigating from the Start menu to Programs → ZiLOG ZDS II - eZ80Acclaim! <Version> → ZDS II - eZ80Acclaim! <Version>. 10. From the File menu in ZDS II, choose Open Project, and navigate to the following file path: c:\Program Files\ZiLOG\ZDSII_eZ80Acclaim!_<Version>...
  • Page 8 Modular Development Kit 21. To run the application, select Debug → Go. Unless the changes are done to the default settings, the following output is displayed in the Hyperterminal window: ZiLOG Developers Studio i = 5 d = 25 f = 1.260000...

  • Page 9: Related Documentation

    11. Using the cycle-accurate simulator, you can view the sample code to study how it works. You can obtain a sample ZiLOG ZTP web application and an embedded secu- Note: rity SSL application by following the instructions on your kit registration card.

  • Page 10: Life Support Policy

    Z8, Z8 Encore!, Z8 Encore! XP, Z8 Encore! MC, Crimzon, eZ80, eZ80Acclaim!, and ZNEO are trademarks or registered trademarks of ZiLOG, Inc. All other product or service names are the property of their respective owners.
