Futurecom PDR8000 Programming Manual page 60

Field Name
Multi-NAC Table Maximum 8 pairs
Enabled Checkbox
Rx NAC (hex) 000-FFF
Tx NAC (hex) 000-FFF
Error report:
Delete
Apply ACT # xx to
CH # yy
Update Access
Code Table # xx
Exit
Within each digital Access Code Table is a setting for the Rx NAC Operation mode to be utilized by
channels pointing to this table. The four modes of Rx NAC Operation are:
(i) Normal
(ii) Receiver Monitor $F7E
(iii) Community Repeater $F7F
(iv) Multi NAC
2021-11-0
Options / Units
Defines up to eight Rx and Tx Network Access
Code pairs for the specified Access Code Table.
Identifies if current row of the table is enabled
for use.
Defines receive ASTRO Network ID.
Defines transmit ASTRO Network ID
Displays any warnings or errors related to the
creation of Rx/Tx NAC pairs in the Multi-NAC
table.
Pressing this button deletes all entries in this
row of the table and shifts all rows beneath up
by one row.
Clicking on this tab applies the NAC values ACT #
xx to CH yy
In the "Channel Configuration' Channel # yy
Updates the Access Code Table ACT# xx in the
"Channel Configuration"
Exits the Table
PDR8000® Portable Digital Repeater Programming Guide
Description
8K088X04 R5.00
Notes
If Rx NAC
Operation is set
to Multi-NAC, all
rows in the Multi-
NAC table are
accessible. If Rx
NAC Operation is
not set to Multi-
NAC, only the first
row in the Multi-
NAC table is
accessible.
Page 60 of 98
