Field Name Options / Units
Monitor Before Disabled Enabled
Data Tx
Tx Inhibit Disabled
Enabled
Base Station ID Maximum 20
alphanumeric
characters
(uppercase letters
only)
Sq. On Tr 4-28 dB SINAD
15 dB
Sq. Off Tr 3-25 dB SINAD
10 dB
ON/OFF Trigger RSSI
Squelch
Sq &RSSI
2021-11-0
PDR8000® Portable Digital Repeater Programming Guide
Description
Disabled: PDR8000 does not monitor
or notify the infrastructure of any co-
channel users.
Enabled: PDR8000 monitors the Rx
channel for co-channel users and
notifies the infrastructure
Disabled: PDR8000 transmits on the
selected channel.
This is default setting.
Enabled: PDR8000 does not transmit
if this field enabled.
Used for automatic, periodic, over-
the-air transmission of the
PDR8000's call sign.
If empty BSID will not be transmitted.
Squelch ON Threshold
Squelch OFF Threshold
Analog Mode – any ON/OFF trigger
can be selected.
Digital Mode – RSSI only allowed.
Mixed Mode – RSSI only allowed.
8K088X04 R5.00
Notes
Enabled: If a co-channel user is
detected, the PDR8000 will notify the
infrastructure (wireline) every 5
seconds. The PDR8000 will not
transmit data once it receives this
message. When co-channel activity
stops, the PDR8000 will again notify
the infrastructure (wireline). The
PDR8000 will resume data
transmission once it receives this
message.
Assigned on a per channel basis,
allowing pre-configuration of
different call signs on channels that
are used for different geographical
deployments.
When Trigger is selected as Squelch
When Trigger is selected as Squelch
Squelch is invalid setting in Digital or
Mixed Mode PDR8000 Channels.
