Field Name
RF Power
RF Power
RF Power
Squelch ON
Threshold
Squelch OFF
Threshold
Temp
PA Temp
RSSI ON Threshold
2021-11-0
Options / Units
dBm PDR8000 transmitting RF power
in dBm
W PDR8000 transmitting RF power
in W
dB SINAD Sets the Squelch ON Threshold.
dB SINAD Sets the Squelch OFF Threshold.
Celsius PDR8000 internal temperature
Celsius RF Power Amplifier temperature
dBm Sets the RSSI ON Threshold
PDR8000® Portable Digital Repeater Programming Guide
Description
8K088X04 R5.00
Notes
Read only
Read only
Affects Analog Mode only.
Typical recommended setting
ON: 16dB SINAD.
If this field is temporarily modified in
Monitoring Window for "tuning" the
PDR, however leaving the Monitoring
Screen will result in reverting to the
previously programmed/saved values
Affects Analog Mode only.
Typical recommended setting
OFF: 10dB SINAD.
If this field is temporarily modified in
Monitoring Window for "tuning" the
PDR, however leaving the Monitoring
Screen will result in reverting to the
previously programmed/saved values
Read only
Read only
Typical recommended setting
Is -115 dBm.
If this field is temporarily modified in
Monitoring Window for "tuning" the
PDR, however leaving the Monitoring
Screen will result in reverting to the
previously programmed/saved values
