Service

The Futurecom Repeater Configurator (FRC)'s Monitoring Screen is provided to assist the field technician
with PDR8000 setup and troubleshooting. The Monitoring screen provides real time indication of the
RSSI level, RF Power, NAC, PL/DPL detection, BER measurement & display of Signal quality as described
below.
Note that the fields Squelch ON Thresh, Squelch OFF Thresh, RSSI ON Threshold may be temporarily
modified in Monitoring Window for "tuning" the PDR, however leaving the Monitoring Screen will result
in reverting to the previously programmed/saved values.
The user must make permanent changes to these configuration values via the normal editing screens in
the Futurecom Repeater Configurator (FRC), not through the Monitoring screen
IMPORTANT!
It must be noted that the Monitoring screen application is not intended to replace the use of
properly calibrated test equipment in the field.
