Field Name Options / Units
Enabled No
Yes
Channel Name Maximum 16
alphanumeric
characters.
Channel Type Analog
Digital
Mixed
Channel Mode F.Duplex
Simplex
H.Duplex
Rx Freq. (MHz) MHz
Tx Freq. (MHz) MHz
2021-11-0
PDR8000® Portable Digital Repeater Programming Guide
Description
Used to enable/disable channels
relevant to the location the PDR8000
is deployed in.
Name that identifies the channel.
Determines the PDR8000 Channel
type.
Determines the PDR8000 mode of
operation for the current channel,
Full Duplex, Half Duplex.or Simplex
Receive frequency for the current
channel.
Transmit frequency for the current
channel.
8K088X04 R5.00
Notes
This field is also updated based on
Repeater Operation (as configured in
the RF Configuration window).
Ch1 has to be enabled.
Underscore may not be used in the
Channel name as it will be displayed
as space on the PDR8000 display.
Analog & Mixed Channels work with
PDR8000 in Repeater mode only.
- Repeater Mode: only Full Duplex
Channels are enabled
- Base Station Mode: Full Duplex,
Half Duplex or Simplex channels are
enabled.
When Hardware Platform is set to
Satellite Tx or channel mode to
Simplex, this field is read only and is
disregarded.
Must equal Channel-0 Base
Frequency plus an integer multiple of
Channel No. Spacing as defined in
Frequency Band Configuration
window.
Must also match the PSU Transmit
Frequency.
When Hardware Platform is set to
Satellite Rx, this field is read only and
is disregarded.
Must equal Channel-0 Base
Frequency plus an integer multiple of
Channel No. Spacing as defined in
Frequency Band Configuration
window.
Must also match the PSU Receive
Frequency.
