Futurecom PDR8000 Programming Manual page 47

Field Name
Audio Limit
12.5kHz
25kHz
25kHz
(NPSPAC)
PL
12.5kHz
25kHz
25kHz
(NPSPAC)
DC Voltage Alarm Levels
Low Voltage Alarm
High Voltage Alarm
Temperature Alarm
2021-11-0
Options / Units
0.75–2.52 kHz Typically set to 2.12kHz (12.5kHz
channel spacing) or 4.24 kHz (25kHz
2.13 kHz
channel spacing or 3.41 kHz (25 kHz
NPSPAC channel spacing).
1.5 – 5.04 kHz
4.26 kHz
1.20-4.03 kHz
3.41 kHz
Typically set to 0.38kHz (12.5kHz
channel spacing) or 0.75kHz (25kHz
0.19-0.60 kHz
channel spacing) or 0.60 kHz (25 kHz
NPSPAC channel spacing).
0.38 kHz
0.38-1.2 kHz
0.75 kHZ
0.30-0.96 kHz
0.60 kHZ
0, 10 - 14 Volts
Voltage level that triggers the Low
Battery Alarm.
(0 = disabled,
displays as OFF)
Disabled
0, 16.0V to 17.0V Voltage level that triggers the DC
Voltage High Alarm.
(0 = disabled,
displays as OFF)
Disabled
50 –100 deg C
PDR8000 activates the temperature
alarm if the RF transmitter module
0 = OFF
temperature exceeds this threshold.
PDR8000® Portable Digital Repeater Programming Guide
Description
8K088X04 R5.00
Notes
Affects Analog Mode only.
Depends on the selected Channel
Spacing – refer to the Frequency
Band Setup menu.
Affects Analog Mode only.
Depends on the selected Channel
Spacing – refer to the Frequency
Band Setup menu.
Typically set to OFF
Typically set to OFF
Typically set to OFF
Page 47 of 98
