Futurecom PDR8000 Programming Manual page 75

Field Name
Synthesizer
DC Voltage
Antenna Switch
DFSI*
Host IP Address
Host Control Port
Host Voice Port
Heartbeat Period
(sec)
Booster Pack
Booster Pack
Connected
Booster Pack State
Ambient
Temperature
2021-11-0
Options / Units
Locked Current state of the Synthesizer
Out of Lock
Normal DC Voltage
High
Low
Normal Current antenna switch position
Reverse
0.0.0.0 Shows the IP Address of the DFSI
Host
Max 65535 UDP Port at which the fixed
station supplies the Control
Service.
Max 65535 UDP Port at which the fixed
station supplies the Voice
communication.
5-55 Periodicity of Host Heartbeats at
which the PDR8000 expects a
heartbeat from the host.
OFF ON: Booster Pack connected to
the PDR8000.
ON
OFF: Booster Pack not
connected
ACTIVE
ACTIVE: When the Booster pack
is connected and powered up.
Celsius Booster Pack Internal
temperature.
PDR8000® Portable Digital Repeater Programming Guide
Description
8K088X04 R5.00
Notes
Read only
Read Only
Read Only
IPv4 address for the DFSI host. Provided
to PDR8000 by the host when PDR8000
wireline interface is set to DFSI.
Provided to PDR8000 by the host when
PDR8000 wireline interface is set to DFSI.
Provided to PDR8000 by the host when
PDR8000 wireline interface is set to DFSI.
Provided to PDR8000 by the host when
PDR8000 wireline interface is set to DFSI.
The PDR8000 detects the Booster Pack
when connected via the AUX Port.
Read only
For Hardware Rel.4-Booster pack is
connected and of matching frequency
band.
Read Only
Page 75 of 98
