After making the necessary changes to all the settings on the various Futurecom Repeater Configurator
(FRC) screens, the new personality can be saved to the PDR8000 by executing any of the following:
1. PDR→ Save Changes to PDR Repeater
2. OR
3. F4
4. OR
5. PDR→ EEprom Maintenance (Ctrl+E) → Changes ->PDR
6. OR
7. Click on the EEprom Maintenance Icon → Changes -> PDR
Reset the repeater (after the changes are saved) in order to ensure the changes are in effect. Resetting
of the PDR8000 can be done by executing any of the following methods:
•
PDR→ Reset PDR Repeater
•
OR
•
F3
•
OR
•
EEprom Maintenance → Reset Repeater
When the PDR8000 personality has been changed and the changes are not causing any detected errors,
the EEprom maintenance icon is flashing yellow. Clicking on the icon opens the EEprom screen which
offers the options of saving the changes to the PDR8000 and resetting the PDR8000. If the data changes
contain errors, the EEprom icon is flashing red and the screens containing conflicting data will be
marked with a red exclamation mark. In this case, the changes cannot be written to the PDR8000
EEPROM until the errors are eliminated.

Futurecom Repeater Configurator (FRC) Icons

The Futurecom Repeater Configurator (FRC) window on the top of the menu tree (left-hand
side) displays icons for quick access to some of the menu items. The icons and their functionality
are described below.
