Field Name
Tx PL/DPL selected 1-30 min
by Last Rx PL/DPL
5 min
Duration
Multi-PL/DPL Table Maximum 14 pairs
Enabled Checkbox
Rx PL/DPL STE deg/DPL
Rx PL/DPL PL: 67.0-254.1
DPL: d-023-d-754
Tx PL/DPL 67.0-254.1
DPL: d-023-d-0754
Tx PL/DPL STE deg/DPL
Delete
2021-11-0
Options / Units
Defines how long the last Rx PL/DPL is used for
transmissions after the last received call. Each
received call restarts the timer.
Defines up to 14 Rx and Tx Network Access Code
pairs for the specified Analog Code Table.
Identifies if current row of the table is enabled
for use.
Analog PSU PL/DPL STE-Squelch Tail Elimination
– must be programmed to match the PSU.
Defines receive PL/DPL.
Defines transmit PL/DPL
Analog PSU PL/DPL STE-Squelch Tail Elimination
– must be programmed to match the PSU
Pressing this button deletes all entries in this
row of the table and shifts all rows beneath up
by one row.
PDR8000® Portable Digital Repeater Programming Guide
Description
8K088X04 R5.00
Notes
This field is
accessible only
when Tx PL/DPL
Selected By Last
Rx PL/DPL is
Enabled.
If Rx PL/DPL
Operation is set
to Multi-PL/DPL,
all rows in the
Multi-PL/DPL
table are
accessible. If Rx
PL/DPL Operation
is not set to
Multi-PL/DPL,
only the first row
in the Multi-
PL/DPL table is
accessible.
