Field Name Options / Units
Tx Pwr (dBm) 30-43 dBm
30.00 dBm
Tx Pwr (Watts) 1-20 Watts
1.0 Watts
NAC Table Index 1-64
NAC Code Table Link, Maximum 10
alphanumeric
characters
ANA Table Index 1-64
Analog Code Table Link, Maximum 10
alphanumeric
characters
2021-11-0
PDR8000® Portable Digital Repeater Programming Guide
Description
Specifies the transmit power at the
Power Amplifier output of the
PDR8000
Specifies the transmit power at the
Power Amplifier output of the
PDR8000 in (W)
Identifies which of the 64 possible
Access Code Tables applies to the
current channel.
Identifies by name and provides a
link to open up the Channel – Access
Code Table ASTRO NAC Assignments
window associated with the current
channel.
Identifies which of the 64 possible
PL/DPL Tables applies to the current
channel.
Identifies by name and provides a
link to open up the Channel – Analog
Code Table PL/DPL Assignments
window associated with the current
channel.
8K088X04 R5.00
Notes
When Hardware Platform is set to
Satellite Rx, this field is read only and
is disregarded.
Read only
This is a read only field that displays
the name of the Access Code Table
only when configured in Channel –
Access Code Table ASTRO NAC
Assignments window.
This is a read only field that displays
the name of the Analog Code Table
only when configured in Channel –
Analog Code Table PL/DPL
Assignments window.
