Field Name
Rx NAC Operation
Normal
Receiver Monitor $F7E
Community Repeater
$F7F
Multi NAC
2021-11-0
Options / Units
Controls the mode of received Network Access
Code operation.
Normal- Receiver operation allows PDR8000 to
accept incoming RF frames containing a specific
NAC value as defined by the Rx NAC field in the
first row of Multi-NAC table. Repeater and
console calls are transmitted using the Tx NAC
field value as defined in first row of Multi-NAC
table.
Receiver Monitor $F7E - Receiver operation
allows a PDR8000 to accept incoming RF frames
containing any NAC value. Repeater and console
calls are transmitted using the same fixed NAC.
Community Repeater $F7F - Community
Repeater operation allows a PDR8000 to accept
incoming RF frames containing any NAC value.
ASTRO® packets are repeated with the same
NAC that was received by the incoming
transmission. Infrastructure packets are
transmitted using a fixed Tx NAC.
Multi NAC - Multi-coded squelch allows you to
predefine a set of accepted Rx NAC and
associated Tx NAC being used by repeat and
infrastructure calls. (Requires Multi Coded
Squelch Enabled)
PDR8000® Portable Digital Repeater Programming Guide
Description
8K088X04 R5.00
Notes
A DFSI-connected
console may
utilize this
functionality by
specifying Tx NAC
of $F7E, or may
override this
behavior by
providing a
specific Tx NAC as
part of the
transmission
information.
