Futurecom PDR8000 Programming Manual page 72

Field Name
Rx State
Rx Source
Rx NAC
Rx PL/DPL
TalkGroup
Subscriber
ID(Decimal)
Transmitter Activity
Tx
Tx Source
Tx NAC
Tx PL/DPL
TalkGroup
Tx Power Alarm
P25 Rx Modem Test
2021-11-0
Options / Units
Idle Specifies the Receiver Activity
Active
Inbound Displays if the PDR8000 is
receiving from the Subscriber or
Outbound
transmitting on V.24 Link.
Displays the received NAC from
the Subscriber
Displays the received PL/DPL
from the Subscriber
Displays the Subscriber
Talkgroup ID
Displays the Subscriber ID in
decimal format
Idle
Specifies the Transmitter
Activity
Active
Inbound
Displays if the PDR8000 is
receiving from the Subscriber or
Outbound
transmitting on V.24 Link.
Displays the NAC transmitted to
the Subscriber
Displays the PL/DPL received
from the Subscriber
PDR8000 activates the Txt
power alarm if the difference in
the measured RF Tx power and
programmed Tx power exceed
this threshold.
PDR8000® Portable Digital Repeater Programming Guide
Description
8K088X04 R5.00
Notes
Page 72 of 98
