Field Name
PDR Operating
Mode
PDR Status
PTT
Repeater State
Deployment
Channel
Toggle Gate Status
Receiver Activity
2021-11-0
Options / Units
Normal Specifies the current mode of
operation
Service
Normal: PDR8000 is operating
as programmed
Service: PDR8000 is operating
with user initiated PTT Tx only
Active
Displays the current PDR8000
status
Idle
PTT OFF PTT OFF: PDR8000 not
transmitting
PTT ON
PTT ON: PDR8000 transmitting.
CARRIER
CARRIER: Carrier Tx only
Test Tone
Test Tone: Transmit 1011 digital
V.52 Test Pattern
test tone
V.52 Test Pattern: digital test
Signal
Repeat Set up Indicates the PDR8000
operation as Base station or
Repeat Knocked
Repeater
Down
Base station
1-10 Identifies the current
Deployment of the 10 possible
deployments
1-64 Identifies the current channel of
the 16 possible channels
Set Up/ Toggles the Repeater Gate
Status between 'Set up' and
Knocked Down
'Knocked Down' if Wireline
Interface is selected as'V.24'.
Refer to 'General Configuration'
of the Deployment Settings.
PDR8000® Portable Digital Repeater Programming Guide
Description
8K088X04 R5.00
Notes
User configurable.
When PDR8000 is operating in Service
mode, transmissions are initiated only by
using the front panel PTT button or the
PTT configurable field in this window.
Read only
User configurable- available in-Service
Mode only
Programmable in the Futurecom
Repeater Configurator (FRC) 'RF
Configuration' menu.
Read only.
PDR8000 must be have the V.24 option.
