Field Name
Station Name
Hardware Platform
System Type
Site ID
Wireline Configuration
Wireline Interface
V.24 Transmit Clock
2021-11-0
Options / Units
Maximum 31 A unique name or alias that identifies
alphanumeric the PDR8000.
characters except
for _"? ' % * .
PDR Identifies the hardware platform for
this PDR8000.
Satellite Rx
Satellite Tx
Conventional System type supported is
Conventional.
1-62 When the Wireline Interface is set to
V.24, this field is used as the Terminal
1
Endpoint Identifier number.
None Select the wireline interface to be
used.
V.24
DFSI
Internal This specifies the source of the V.24 Tx
Clock. This is needed for PDR8000
External
cross connect (RT/RT) and some
modems
Internal: The PDR8000 provides the
clock. This choice is typically selected
when the radio is connected directly to
an infrastructure device.
External: An external device (e.g. a
Modem) is providing the V.24 clock.
PDR8000® Portable Digital Repeater Programming Guide
Description
8K088X04 R5.00
Notes
This is a ready only field.
If None is selected, the other
Wireline Configuration fields are
disabled.
This field is enabled when
Wireline Interface is set to V.24.
