Futurecom PDR8000 Programming Manual page 66

Field Name
Multi PL/DPL
Enabled
Disabled
Tx PL/DPL Selected
by Last Received Rx
PL/DPL
Enabled
Disabled
2021-11-0
Options / Units
Multi PL/DPL - Multi-coded squelch allows you
to predefine a set of accepted Rx PL/DPL and
associated Tx PL/DPL being used by repeat calls.
Receiver operation allows PDR8000 to accept
incoming RF signal containing a specific PL/DPL
value as defined by the Rx PL/DPL field in the
first row of Multi-PL/DPL table. Repeater calls
are transmitted using the Tx PL/DPL field value
as defined in first row of Multi-PL/DPL table.
Receiver operation allows PDR8000 to accept
incoming RF signal containing a specific PL/DPL
value as defined by the Rx PL/DPL field in all the
14 rows if 'Enabled' in the Multi-PL/DPL table.
Repeater calls are transmitted using the Tx
PL/DPL field value as defined in the Multi-
PL/DPL table.
Specifies how Tx PL/DPL is selected for
transmitting the infrastructure audios.
Enabled: When the Tx PL/DPL Selected by Last
Rx PL/DPL Duration has not expired, the Tx
PL/DPL is selected according to following rules:
For Multi-NAC operation, Tx PL/DPL is set to the
programmed Tx PL/DPLL from the row in the
Multi-NAC table where Rx PL/DPL is equal to the
last received Rx PL/DPL.
Disabled: or Tx PL/DPL Selected by Last Rx NAC
Duration has expired, the Tx PL/DPL is set to the
programmed Tx NAC from the first row in the
Multi-PL/DPL Table.
PDR8000® Portable Digital Repeater Programming Guide
Description
8K088X04 R5.00
Notes
Page 66 of 98
