Futurecom PDR8000 Programming Manual page 44

Field Name
Fallback In-Cabinet
Repeat
Fallback
Determination Time
Local PTT Test Tone
Repeater
Repeater Operation
2021-11-0
Options / Units
Disabled Disabled: when the link failure is
detected, the PDR8000 does not
Link Failure
automatically activate its local repeat
capabilities.
Link Failure or
Timer
Link Failure: when the link is
disconnected, the PDR8000 does
automatically activate its local repeat
capabilities.
Link Failure or Timer: when the link is
disconnected, or the Fallback
Determination Time expires, then the
PDR8000 does automatically activate
its local repeat capabilities.
180ms Amount of time the PDR8000 waits for
an outbound payload from the
50-10000ms
infrastructure after sending an
inbound payload via the wireline
interface.
Check box When disabled, pushing the Local PTT
button transmits an RF carrier on the
active channel.
When enabled, pushing the Local PTT
button transmits a 1 kHz test tone on
the active channel.
Base Specifies whether station is operating
as a Base Station or a Repeater.
Repeater
PDR8000® Portable Digital Repeater Programming Guide
Description
8K088X04 R5.00
Notes
This field is not applicable to
channels in Half Duplex or
Simplex Mode.
When Wireline Interface is set to
None, this field must be set to
Disabled.
This timer is used when the
Fallback In-Cabinet Repeat is set
to Link Failure or Timer.
This field is disregarded when
Fallback In-Cabinet Repeat is set
to Disabled or Link Failure.
Base- local repeat is unavailable
(Full Duplex, Half Duplex and
Simplex are supported)
Repeater- local repeat available
on Full Duplex channels only
(depending on Gate Parameters)
Page 44 of 98
