Fig. 2: Fitting the wall bracket
5.
Screw the wall bracket into position using the washers, see
Fig. 2
2
1
Fig. 3: Fitting the wall bracket
6.
Hook the bottom of the housing (1) into the wall bracket
7.
Lightly press the housing at the top (2) against the wall
bracket
8.
Then check that the housing is hooked in at the top and
press down (3) until it audibly engages
Assembly and Installation
A0491
3
A0492
13
