Assembly and operating instructions
DULCODOS Pool Comfort
EN
A1723
Please carefully read these operating instructions before use. · Do not discard.
The operator shall be liable for any damage caused by installation or operating errors.
The latest version of the operating instructions are available on our homepage.
Part no. 984198
Original Operating Instructions (2006/42/EC)
Version: BA DD 033 04/15 EN
