Section 1
GENERAL INFORMATION
UNPACKING
The 8001 /8002 µProcessor Lab and Flexible Disc Unit are shipped in separate cartons.
Before unpacking these units, inspect each carton for signs of external damage. If any
damage is detected, contact your nearest Tektronix representative.
Unpacking the 8001 /8002 µProcessor Lab
To unpack the 8001i8002 µProcessor Lab, open the outer carton and remove the co!"ner
packing supports. Lift the inner carton and place on a flat surface. Remove the coiled
power cord taped to the top of the inner carton and set it aside until the unit is to be
connected to the primary power source. Open both ends of the inner carton and slide the
µProcessor Lab out of the carton. Remove the plastic bag, cardboard packing, and front
panel protective foam cushion from around the unit. The top cover is secured to the
µProcessor Lab with three screws located along each side of the unit. Remove the screws
and lift the top cover straight up. Set the cover aside. Remove the protective foam cushion
on top of the modules (printed circuit boards).
Unpacking the Flexible Disc Unit
To unpack the Flexible Disc Unit, follow the same procedure for removing the outer
carton, inner carton, and protective cushion as for the µProcessor Lab. Remove the three
screws along each side and lift the top cover straight up. Set the cover aside. Visually
inspect the inside of the unit for physical damage that may occur during shipping. Uncoil
the Flexible Disc Unit interconnect cable and feed it through the channel opening provided
in the rear panel. Replace the top cover on the Flexible Disc Unit.
