A.5.5 Wireless LAN interface
WLAN standards
Concurrent 2.4 and 5 GHz sup-
ported modes
Frequency bands 2.4 GHz in-
door and outdoor (EU)
Frequency bands 2.4 GHz in-
door and outdoor (USA)
Frequency bands 5 GHz indoor
(EU), indoor and outdoor (USA)
Frequency bands 5 GHz indoor
and outdoor (EU/USA)
Frequency bands 5 GHz indoor
and outdoor (USA)
Modulation Techniques
Automatic Rate Selection (ARS) Available.
Transmission rate
Data rates
Output power limitation
Output Power
Teldat M2/M2L
802.11 a/b/g/n/ac/ax MIMO 2x2 Dual-Band, Dual-Concurrent
5 GHz
2.4 GHz
Scn Mode Tech
1 2x2 802.11n
2 2x2 802.11n
3 2x2 802.11ax
2400-2483.5 MHz: max. 100 mW EIRP (20dBm).
2400-2473 MHz: max. 100 mW EIRP (20dBm).
5170-5330 MHz; max. 200 mW EIRP allowed
5490-5710 MHz; max. 1000 mW EIRP allowed
5735-5835 MHz; max. 1000 mW EIRP allowed
DSSS, OFDM, DBPSK, DQPSK, CCK, 16 QAM, 64 QAM.
Automatic.
802.11b: 1, 2, 5.5, 11Mbps.
802.11a/g: 6, 9, 12, 18, 24, 36, 48, 54Mbps
802.11n: up to 150Mbps-single
802.11n: up to 300Mbps-2×2 MIMO
802.11ac: up to 192.6Mbps (20MHz channel)
802.11ac: up to 400Mbps (40MHz channel).
802.11ac: up to 866.7Mbps (80MHz channel)
802.11ax: 2.4GHz up to 458Mbps, 5GHz up to 1.2Gbps.
Adjustable
@2.4GHz: Max. 16,35 dBm
@5GHz: Max. 18,12 dBm
B/W Mode Tech
40MHz 2x2 802.11ax
40MHz 1x1 802.11ax
1Rx Zero wait
DFS
40MHz 2x2 802.11ac
Technical Information
B/W
80MHz
80MHz
80MHz
40MHz
