Teldat
To mount the router on a wall or any other surface, please follow these steps:
Procedure
Step 1. Install the two screws (3.5x30 mm) horizontally on the desired wall or vertical surface. Make sure they are in-
stalled 116.5 mm (4.56 inches) apart.
The screws should protrude 6 mm (0.25 inch) from the surface of the wall.
Warning
If you are mounting the screws onto drywall, it is recommended to use hollow-wall anchors (8 mm –
5/16 inch) to ensure the screws are securely fastened. Without proper anchoring, the strain from the
cables connected to the router's back panel could potentially cause the router to detach from the wall.
Step 2. Hang the router onto the screws.
3.3.3 19'' Rack installation
The Teldat M2 router family can be easily installed in a 19" rack.
Note
The rack mount kit, consisting of strips and screws, is not included with the router and needs to be pur-
chased separately.
Teldat M2/M2L
3 Components and Power Supply
13
