A.4.5 xDSL connector
RJ45 CONFIGURATION
A.4.6 Configuration connector
RJ45 CONFIGURATION
A.4.7 Power supply connector
Jack 5.5/2.5mm
A.5 Technical specifications
Teldat M2/M2L
RJ45 PIN
1
2
3
4
5
6
7
8
RJ45 PIN
1
2
3
4
5
6
7
8
PIN
Internal -> POSITIVE
External -> NEGATIVE
CONF
--
--
--
TIP
RING
--
--
--
CONF
--
RxD
GND
--
--
GND
TxD
--
Technical Information
