3 Components and Power Supply
WAN-1 LEDs
Fig. 4:
WAN-1 Ethernet LED indicators
LED
Green
Yellow
None
The following figure shows the router's WAN-2 LED indicators:
WAN-2 LEDs
Fig. 5:
WAN-2 2.5G Ethernet LED indicators
LED
Yellow
Yellow+Green
Green
None
The following figure shows the router's Ethernet switch LED indicators:
8
Description
Copper status
- Steady: 10/100/1000M link established.
- Blinking: Transferring data.
Fiber status:
- Steady: 1000M link established.
Interface is either unavailable, not installed, or not registered.
Description
- Steady: 10/100M link established.
- Blinking: Transferring data.
- Steady: 1000M link established.
- Blinking: Transferring data
- Steady: 2.5G link established.
- Blinking: Transferring data
Interface is either unavailable, not installed, or not registered.
