A Technical Specifications; Axs-200/350 - EXFO AXS-200 User Manual

A Technical Specifications
The following technical specifications can change without notice.
The information presented in this section is provided as a reference
only. To obtain this product's most recent technical specifications,
visit the EXFO Web site at www.exfo.com.

AXS-200/350

AXS-200/350 SPECIFICATIONS
Power Meter
Detector
Power range (dBm)
Wavelength range (nm)
Calibrated wavelengths (nm)
Power uncertainty
Resolution (dB)
Automatic offset nulling
Display units
Tone detection
Auto-switching
Warm-up period (min)
Data storage (fibers)
Battery life (hours) (typical in Auto mode)
Recommended calibration interval (years)
Source Model
Nominal wavelength (nm)
Spectral width
Output power (dBm)
Auto-switching
Tone generation
Battery life (hours) (typical in Auto mode)
Automatic wavelength recognition
GENERAL SPECIFICATIONS
Module size (H x W x D)
Module weight (with battery)
Temperature
operating
storage
Humidity
Power supply input
Power supply output
Battery
Self-test
Results storage
Languages
Warranty (years)
i
VFL
Emitter type
Wavelength (nm)
Output power (dBm)
OLTS and Power Meter
a
PRELIMINARY
b AXS-200/352
Ge
c 10 to −70
800 to 1650
800, 820, 830, 840, 850, 860, 870, 880, 910, 980,
1270, 1280, 1290, 1300, 1310, 1320, 1330, 1340,
1350, 1370, 1390, 1410, 1430, 1450, 1460, 1470,
1480, 1490, 1500, 1510, 1520, 1530, 1540, 1550,
1560, 1570, 1580, 1590, 1600, 1610, 1620, 1630,
1640, 1650
d
±5 % ± 0.1 nW
±0.01 (10 dBm to −60 dBm)
e
Yes
dB, dBm, W
270 Hz, 1 kHz and 2 kHz
f
Yes
e 0
More than 10000
7.5
g
3
12D
850
1300
h (nm) 50/135
≥ –20/≥ –20 (62.5/125 μm)
Yes
270 Hz, 1 kHz, 2 kHz
7.5
Yes
284 mm x 125 mm x 78 mm
0.98 kg
0 °C to 50 °C
—20 °C to 70 °C
5 % to 95 % relative, non-condensing
110-240 V to AC at 1.8A, 50 Hz to 60 Hz
18 V to 24 V DC at 3.33 A to 2.50 A, 60 W
Internal rechargeable Li-Ion battery, with battery state indication
Routine on power-up
128 Mbyte
English, French, German, Spanish, Chinese (Simplified)
3
Laser
650
3
I
MPORTANT
AXS-200/352X
GeX
26 to −55
800 to 1650
Same calibrated wavelengths as the AXS-352 plus 1060
±5 % ± 3 nW
±0.01 (26 dBm to −45 dBm)
Yes
dB, dBm, W
270 Hz, 1 kHz and 2 kHz
Yes
0
More than 10000
7.5
3
23BL 234BL
1310 1310
1550 1550
1625
≤ 5 ≤ 5
≥ 1/≥ 1 ≥ 1/≥ –3/≥ –5
Yes Yes
270 Hz, 1 kHz, 2 kHz 270 Hz, 1 kHz, 2 kHz
7.5 7.5
Yes Yes
(11 3 / in x 4 15 / in x 3 1 / in)
16 16 16
(2.16 lb)
(32 °F to 122 °F)
(—4 °F to 158 °F)
SAFETY
21 CFR 1040.10 and IEC 60825-1:1993+A1:1997+A2:2001:
CLASS 1M LASER PRODUCT
CLASS 3R LASER PRODUCT FOR VFL
235BL
1310
1490
1550
≤ 5
≥ 1/≥ –4.5/≥ –3
Yes
270 Hz, 1 kHz, 2 kHz
7.5
Yes
If VFL option is available
IEC 60825-1:1993+A2:2001
21 CFR 1040.10
LASER RADIATION
AVOID DIRECT EYE EXPOSURE
CLASS 3R LASER PRODUCT
λ: 650 ±10 nm
P out maximum < 5mW (into free space)
53
