Using a Source

Changing the Source Modulation Mode

When you activate the source, the signal is always CW (unmodulated).

The available modulation values are: 270 Hz, 1 kHz,2 kHz. You can also

have a continuous signal (CW) and two special modes (auto-wavelength,

and auto-switching).

Note: The Auto-switching mode sends a signal that can only be detected by

compatible power meters.

To change the signal modulation:

1. Press

Source.

2. Using the arrows next to the

function keys (F1/F2/F3), select

the View tab.

3. Using the up/down arrows, select

Mode and press

4. Select the required mode and

press

and select Light

AXS-200/350 and AXS-200/360
