Introducing the OSA20

The OSA20 is a diffraction-grating based optical spectrum analyzer, using a touch sensitive
display with multi-touch gesture control. It provides an extensive suite of built-in analysis
functions enabling input signal measurement and analysis for many common applications.
A wide range of communication ports allows remote control operations and export of data.
The OSA20 features one general analysis mode and seven application-oriented modes.
Each analysis mode has a full suite of analysis functions for a detailed spectrum analysis.

Technical Specifications

The following technical specifications can change without notice. The information
presented in this section is provided as a reference only. To obtain this product's
most recent technical specifications, visit the EXFO Web site at www.exfo.com.
Wavelength Spectral range
Span range
Linearity
Accuracy
Repeatability
Sampling resolution
Sampling points
Reference
Monochromator Resolution bandwidth
Dynamic range (ORR)
Stray light suppression ratio
OSA20
I
Optical Measurement
a
a.
b, c, d
e
f
MPORTANT
1250–1700 nm / 239.834–176.349 THz
0.5 nm to full range (450 nm)
±6 pm over 1500–1640 nm, ±20 pm over full range /
2.5 GHz @ 1550 nm
±10 pm over 1500–1640 nm, ±25 pm over full range /
2.5 GHz @ 1550 nm
±2 pm / 0.25 GHz @ 1550 nm
2 pm / 0.25 GHz @ 1550 nm
251 (span of 0.5 nm) to 225,001 (span of 450 nm)
Built-in ELED (safety class 1) + Acetylene cell (user
calibration by patch cord)
Acetylene gas is a NIST standard Reference Material
SRM 2517a. The P9 line is used in the case of OSA20
20 pm native, adjustable over 50–2000 pm with 1 pm
step
≥ 30 dB (> 35 dB typ.) beyond ±50 pm from peak
≥ 50 dB (> 55 dB typ.) beyond ±100 pm from peak
≥ 60 dB (> 63 dB typ.) beyond ±200 pm from peak
≥ 73 dB
