To revert to factory settings:
Press Revert to Factory Settings.
To set the pass/fail thresholds for Network standard:
1. Press
and then Configuration.
2. Select the Thresholds tab.
3. Using the up/down arrows, select
Threshold type, and press
4. Select Network standard and
press
5. From Standard, select one of the
predefined thresholds or select User defined values to set your own
threshold.
If you have chosen User defined values, you should name your
threshold configuration in the Filename box, and press Save.
6. Enter the threshold parameters for each wavelength.
Note: All Network standards assume the attenuation budget at maximum system
length as determined by TIA/EIA 568.
OLTS and Power Meter
, select Power Meter,
.
Measuring Power or Loss
Setting Pass/Fail Thresholds
.
