A Technical Specifications
The following technical specifications can change without notice.
The information presented in this section is provided as a reference
only. To obtain this product's most recent technical specifications,
visit the EXFO Web site at www.exfo.com.
SPECIFICATIONS
Model
Number of detectors
Detector type
Detector size (mm)
Wavelength range (nm)
Power range
c
Uncertainty
Polarization dependent responsivity
Linearity e (dB)
Power resolution (dB)
Wavelength resolution (nm)
Stabilization time (ms)
automatic range
automatic range
fixed range (ranges 1 to 4)
Sampling rate (sample/s/channel)
fast acquisition mode
continuous measurement mode
Fiber type (μm)
High Speed Power Meter
a
(IQS-1600 Series)
IQS-1613/1623/1643
1/2/4
InGaAs
1
800 to 1700
b, j
(dBm) 9 to 85
(%) ±5
(0 dBm to 55 dBm)
d
(dB) N/A
±0.015 (0 dBm to 55 dBm)
0.001 (9 dBm to 40 dBm)
0.01
12 (9 dBm to 85 dBm)
3 (9 dBm to 50 dBm)
1
up to 4096
up to 256
5/125 to 62.5/125
I
MPORTANT
IQS-1613-PL/1623-PL/1643-PL
1/2/4
InGaAs
1
800 to 1700
9 to 85
±5
(0 dBm to 55 dBm)
±0.005
±0.015 (0 dBm to 55 dBm)
0.001 (9 dBm to 40 dBm)
0.01
12 (9 dBm to 85 dBm)
3 (9 dBm to 50 dBm)
1
up to 4096
up to 256
5/125 to 62.5/125
IQS-1613W/1623W/1643W
1/2/4
InGaAs
3
800 to 1700
8 to 75
±5
(0 dBm to 50 dBm)
N/A
±0.015 (0 dBm to 50 dBm)
0.001 (8 dBm to 40 dBm)
0.01
6 (8 dBm to 75 dBm)
3 (8 dBm to 49 dBm)
1
up to 4096
up to 256
5/125 to 62.5/125
