Measuring Power or Loss
Referencing Your Power Meter to a Source
To reference the power meter to a source manually:
1. Using the proper adapter, connect the source to your power meter.
Note: You can set the reference with one, two, or three reference jumpers.
However, keeping a record of the number of jumpers used can only be
done when you use the Loss Certification Wizard to configure the unit.
2. Activate the source at the desired
wavelength.
3. Press
and then Instrument View.
4. Using the up/down arrows, select
Wavelength, and press
5. Select the matching wavelength,
and press
22
Reference
jumper
Light
source
, select Power Meter,
.
Bulkhead
connector
.
Reference
jumper
Power
meter
AXS-200/350 and AXS-200/360
