Measuring Power or Loss

Defining the Job Information

Defining the Job Information
The Job Information tab allows you to define information about the
company and operator (making the inspection), the customer (requesting
the inspection), and work location.
To define the job information:
1. Press
and then Configuration.
2. Using the arrows next to the
function keys (F1/F2/F3), select
the Job Information tab.
3. Using the up/down arrows, select
the parameter for which you want
to set information, and press
4. Enter the information and press
5. Repeat steps 3 and 4 for all required parameters.
To revert to factory settings:
Press Revert to Factory Settings.
Note: Changes to job information do not apply to data already saved. Report
Viewer only displays job information as entered at the time the cable was
created. If you want to use different information for other fibers in a cable,
create a new cable file.
20
, select Power Meter,
.
.
AXS-200/350 and AXS-200/360
