3 Using the Loss Certification
Wizard
The Loss Certification Wizard allows you to enter all the information
required to take measurements. It helps you to go through the different
steps in order.
Note: You can exit the wizard at anytime by pressing Exit Certification.
To use the Loss Certification Wizard:
1. Press
2. Using the up/down arrows, select
Fiber type and press
3. In the list, select the fiber type and
press
4. Select the threshold type you
intend to use (see Setting Pass/Fail
Thresholds on page 16).
5. Select a transmission standard.
6. Press Next.
7. Select Length measurement
method and press
8. Select one of the following
options:
9. Press
OLTS and Power Meter
, and then select Loss Certification Wizard.
.
Manual entry: when you
know the cable length.
Sheath marking: when you
want to use the provided
marks on the cable sheath to
evaluate the actual length.
and press Next.
.
.
