4. Pinout and Signal Descriptions

4.1 Pin Summary

The below table is a comprehensive list of all signal pins supported on the dual 400-pin COM-HPC connectors (J1 and J2) as defined for Server Type in
the PICMG COM-HPC Rev 1.0 specification. Signals described in the specification but not supported on the COM-HPC-ALT are marked by strikethrough
ROW A/B/C/D on J1 connector, ROW E/F/G/H on J2 connector
Figure 2 – Module Rear Side Row
