4. Pinout and Signal Descriptions

4.1. Pin Summary

The table below is a comprehensive list of all signal pins supported on the dual 400-pin COM-HPC connectors as defined for Server Type in the PICMG
COM-HPC R1.1 specification. Signals described in the specification but not supported on the COM-HPC-sIDH are marked by STRIKETHROUGH.

Figure 2 - Module rear side row and pin numbering
