COM-HPC-ALT User's Guide
PCIe43_TX-
H29
PCIe44_TX+
H33
PCIe44_TX-
H32
PCIe45_TX+
H36
PCIe45_TX-
H35
PCIe46_TX+
H39
PCIe46_TX-
H38
PCIe47_TX+
H42
PCIe47_TX-
H41
PCIe32_RX+
F21
PCIe32_RX-
F20
PCIe33_RX+
F24
PCIe33_RX-
F23
PCIe34_RX+
F27
PCIe34_RX-
F26
PCIe35_RX+
F30
PCIe35_RX-
F29
PCIe36_RX+
F33
PCIe36_RX-
F32
PCIe37_RX+
F36
PCIe37_RX-
F35
PCIe38_RX+
F39
PCIe38_RX-
F38
PCIe39_RX+
F42
PCIe39_RX-
F41
PCIe40_RX+
G22
PCIe40_RX-
G21
PCIe41_RX+
G25
PCIe41_RX-
G24
PCIe42_RX+
G28
PCIe42_RX-
G27
PCIe43_RX+
G31
PCIe43_RX-
G30
PCIe44_RX+
G34
PCIe44_RX-
G33
PCIe45_RX+
G37
PCIe45_RX-
G36
PCIe46_RX+
G40
PCIe46_RX-
G39
Page 15
PCI Express Differential Receive Pairs 32-47
PCIe Group 2
Copyright © 2023 ADLINK Technology, Inc.
I PCIe
AC coupled off Module
PICMG COM-HPC R1.0
