COM-HPC-ALT User's Guide
USB01_OC# B28
USB23_OC# B27
USB45_OC# B26
USB67_OC# B25
RSMRST_OUT#
This platform doesn't support USB4, thus additional signals required by USB4 are not shown here.

4.3.5 Asynchronous Serial Port

Two logic level Module "5 wire" (TX, RX, RTS#, CTS#, GND) asynchronous serial ports are provided for general purpose use and for use with debugging
software that make use of the "console redirect" features available in many BIOS and operating systems. The Module BIOS should support "console
redirect" to the UART0 port.
It is preferred that if the Module is based on an Intel x86 architecture, the Module serial ports be I/O mapped and be register compatible with the
National Semiconductor 16550 UARTs that were used in the PC AT architecture.
Page 20
These ports shall be used in conjunction with the
corresponding USB 2.0 port pair (e.g. USB2_SSxxx+/-
shall be used with the USB2 USB 2.0 pair and
USB3_SSxxx+/- with the USB3 USB 2.0 pair).
USB over-current sense, USB channels 0,1; channels
2,3; channels 4,5 and channels 6,7 respectively.
A pull-up for each of these lines to the 3.3V Suspend
rail shall be present on the Module.
The pull-up should be 10K. An open drain driver
from USB current monitors on the Carrier Board may
drive this line low. The Carrier Board shall not pull
these lines up.
Note that the over-current limits for USB 2.0 and USB
3.0 are different; this is a Carrier board
implementation item.
USB devices that are to be powered in the S5 / S4 /
S3 Suspend states should not have their 5V VBUS
power enabled before RSMRST_OUT# transitions to
the hi state.
RSMRST_OUT# is also described in Power and System
Management section
Copyright © 2023 ADLINK Technology, Inc.
I 3.3VSB PU 10K Do not pull high on carrier
3.3VSB
O
3.3VSB
PICMG COM-HPC R1.0
