4. Pinout and Signal Descriptions

4.1. Pin Summary

The table below is a comprehensible list of all signal pins supported on the dual 220-pin COM Express connectors as defined for Type 7 in the PICMG
COM.0 R3.1 specification. Signals described in the specification but not supported on the Express-ID7 are strikethrough STRIKETHROUGH
Note: The 4 SO-DIMM (grey color) is supported by build option.
th
Page 18
A110

Figure 2 - Module rear side row and pin numbering

Copyright © 2022 ADLINK Technology, Inc.
PICMG COM.0 R3.1
D1
CD
C1
B1
AB
A1
