ADLINK Technology arm AMPERE COM-HPC-ALT User Manual page 30

COM-HPC-ALT User's Guide
Row A
A1 VCC
A2 VCC
A3 VCC
A4 VCC
A5 VCC
A6 VCC
A7 VCC
A8 VCC
A9 VCC
A10 GND
A11 BATLOW#
A12 PLTRST#
A13 GND
A14 USB7-
A15 USB7+
A16 GND
A17 USB6-
A18 USB6+
A19 GND
A20 ETH4_RX-
A21 ETH4_RX+
A22 GND
A23 ETH5_RX-
A24 ETH5_RX+
A25 GND
A26 ETH6_RX-
A27 ETH6_RX+
A28 GND
A29 ETH7_RX-
A30 ETH7_RX+
A31 GND
A32 RSVD
A33 RSVD
A34 GND
A35 ETH4_TX-
A36 ETH4_TX+
Page 1
Row B
B1 VCC
B2 PWRBTN#
B3 VCC
B4 THERMTRIP#
B5 VCC
B6 TAMPER#
B7 VCC
B8 SUS_S3#
B9 VCC
B10 WD_STROBE#
B11 WD_OUT
B12 GND
B13 USB5-
B14 USB5+
B15 GND
B16 USB4-
B17 USB4+
B18 GND
B19 RSVD
B20 RSVD
B21 RSVD
B22 RSVD
B23 RSVD
B24 VCC_5V_SBY
B25 USB67_OC#
B26 USB45_OC#
B27 USB23_OC#
B28 USB01_OC#
B29 SML1_CLK
B30 SML1_DAT
B31 PMCALERT#
B32 SML0_CLK
B33 SML0_DAT
B34 USB_PD_ALERT#
B35 USB_PD_I2C_CLK
B36 USB_PD_I2C_DAT
Copyright © 2023 ADLINK Technology, Inc.
Row C
C1 VCC
C2 RSTBTN#
C3 VCC
C4 CARRIER_HOT#
C5 VCC
C6 VIN_PWR_OK
C7 VCC
C8 SUS_S4_S5#
C9 VCC
C10 GND
C11 FAN_PWMOUT
C12 FAN_TACHIN
C13 GND
C14 USB3-
C15 USB3+
C16 GND
C17 USB2-
C18 USB2+
C19 GND
C20 ETH0_TX-
C21 ETH0_TX+
C22 GND
C23 ETH1_TX-
C24 ETH1_TX+
C25 GND
C26 ETH2_TX-
C27 ETH2_TX+
C28 GND
C29 ETH3_TX-
C30 ETH3_TX+
C31 GND
C32 USB3_SSRX-
C33 USB3_SSRX+
C34 GND
C35 USB2_SSRX-
C36 USB2_SSRX+
PICMG COM-HPC R1.0
Row D
D1 VCC
D2 VCC
D3 VCC
D4 VCC
D5 VCC
D6 VCC
D7 VCC
D8 VCC
D9 VCC
D10 WAKE0#
D11 WAKE1#
D12 GND
D13 USB1-
D14 USB1+
D15 GND
D16 USB0-
D17 USB0+
D18 GND
D19 ETH0_RX-
D20 ETH0_RX+
D21 GND
D22 ETH1_RX-
D23 ETH1_RX+
D24 GND
D25 ETH2_RX-
D26 ETH2_RX+
D27 GND
D28 ETH3_RX-
D29 ETH3_RX+
D30 GND
D31 USB3_SSTX-
D32 USB3_SSTX+
D33 GND
D34 USB2_SSTX-
D35 USB2_SSTX+
D36 GND
