4. Pinout and Signal Descriptions

4.1 Pin Summary

The below table is a comprehensible list of all signal pins on the MXM 3 connector in the standard specification SMARC 2.1.
Signals not supported on LEC-MTK-i1200 are strikethrough STRIKETHROUGH
Top Side Bottom Side
P1 P74 P75 P156 S156 S76 S75 S1
Key Key
Figure 2 – Module top/botom side pin numbering
