COM-HPC-ALT User's Guide
PCIe09_TX+
A66
PCIe09_TX-
A65
PCIe10_TX+
A69
PCIe10_TX-
A68
PCIe11_TX+
A72
PCIe11_TX-
A71
PCIe12_TX+
A75
PCIe12_TX-
A74
PCIe13_TX+
A78
PCIe13_TX-
A77
PCIe14_TX+
A81
PCIe14_TX-
A80
PCIe15_TX+
A84
PCIe15_TX-
A83
PCIe08_RX+
B62
PCIe08_RX-
B61
PCIe09_RX+
B65
PCIe09_RX-
B64
PCIe10_RX+
B68
PCIe10_RX-
B67
PCIe11_RX+
B71
PCIe11_RX-
B70
PCIe12_RX+
B74
PCIe12_RX-
B73
PCIe13_RX+
B77
PCIe13_RX-
B76
PCIe14_RX+
B80
PCIe14_RX-
B79
PCIe15_RX+
B83
PCIe15_RX-
B82
PCIe16_TX+
E46
PCIe16_TX-
E46
PCIe17_TX+
E49
PCIe17_TX-
E48
PCIe18_TX+
E52
PCIe18_TX-
E51
PCIe19_TX+
E55
PCIe19_TX-
E54
PCIe20_TX+
E58
Page 12
A Server Module may map up to 8 higher bandwidth
PCIe lanes to Group 0 High
PCI Express Differential Receive Pairs 8-15
PCIe Group 0 High
A Server Module may map up to 8 higher bandwidth
PCIe lanes to Group 0 High
PCI Express Differential Transmit Pairs 16-31
PCIe Group 1
Copyright © 2023 ADLINK Technology, Inc.
I PCIe
AC coupled off Module
O PCIe
AC coupled on Module
PICMG COM-HPC R1.0
