ADLINK Technology SMARC LEC-MTK-I1200 User Manual page 48

LEC-MTK-i1200 User's Guide
SMARC
Signal Name
P87
PCIE_A_RX-
P88
GND
P89
PCIE_A_TX+
P90
PCIE_A_TX-
P91
GND
P92
HDMI_D2+ / DP1_LANE0+
P93
HDMI_D2- / DP1_LANE0-
P94
GND
P95
HDMI_D1+ / DP1_LANE1+
P96
HDMI_D1- / DP1_LANE1-
P97
GND
P98
HDMI_D0+ / DP1_LANE2+
P99
HDMI_D0- / DP1_LANE2-
P100
GND
P101
HDMI_CK+ / DP1_LANE3+
P102
HDMI_CK- / DP1_LANE3-
P103
GND
P104
HDMI_HPD / DP1_HPD
P105
HDMI_CTRL_CK / DP1_AUX+
P106 HDMI_CTRL_DAT /
DP1_AUX-
P107
DP1_AUX_SEL
P108
GPIO0 / CAM0_PWR#
P109
GPIO1 / CAM1_PWR#
P110
GPIO2 / CAM0_RST#
P111
GPIO3 / CAM1_RST#
P112
GPIO4 / HDA_RST#
P113
GPIO5 / PWM_OUT
P114
GPIO6 / TACHIN
P115
GPIO7
Page 48
Module Termination Type/Tolerance
- PCIe
- -
Serial-0.22uF PCIe
Serial-0.22uF PCIe
- -
- HDMI/DP
- HDMI/DP
- -
- HDMI/DP
- HDMI/DP
- -
- HDMI/DP
- HDMI/DP
- -
- HDMI/DP
- HDMI/DP
- -
- HDMI
- HDMI/DP
- HDMI/DP
- GPIO / 1.8V
PU-470K GPIO / 1.8V
PU-470K GPIO / 1.8V
PU-470K GPIO / 1.8V
PU-470K GPIO / 1.8V
PU-470K GPIO / 1.8V
PU-470K GPIO / 1.8V
GPIO / 1.8V
PU-470K GPIO / 1.8V
copyright © 2023 ADLINK Technology Inc.
Controller Controller Pin Name
MT8395 PCIEG3_LN0_RXN
- -
MT8395 PCIEG3_LN0_TXP
MT8395 PCIEG3_LN0_TXN
- -
HD3SS215IRTQR DC0P
HD3SS215IRTQR DC0N
- -
HD3SS215IRTQR DC1P
HD3SS215IRTQR DC1N
- -
HD3SS215IRTQR DC2P
HD3SS215IRTQR DC2N
- -
HD3SS215IRTQR DC3P
HD3SS215IRTQR DC3N
- -
HD3SS215IRTQR A1
TS5A23159RSER MUX
TS5A23159RSER MUX
Logic IC -
MT8395 GPIO
MT8395 GPIO
MT8395 GPIO
MT8395 GPIO
MT8395 GPIO
MT8395 GPIO
MT8395 GPIO
SX1509BIULTRT I/O1
SGET SMARC Rev 2.1
I/O Mux default
ALT0
ALT0
ALT0
ALT0
ALT0
ALT0
ALT0
