LEC-MTK-i1200 User's Guide
SMARC
Signal Name
S19
GBE1_LINK100#
S20
GBE1_MDI1+
S21
GBE1_MDI1-
S22
GBE1_LINK1000#
S23
GBE1_MDI2+
S24
GBE1_MDI2-
S25
GND
S26
GBE1_MDI3+
S27
GBE1_MDI3-
S28
GBE1_CTREF
S29
PCIE_D_TX+ / SERDES_1_TX+
S30
PCIE_D_TX- / SERDES_1_TX-
S31
GBE1_LINK_ACT#
S32
PCIE_D_RX+ / SERDES_1_RX+
S33
PCIE_D_RX- / SERDES_1_RX-
S34
GND
S35
USB4+
S36
USB4-
S37
USB3_VBUS_DET
S38
AUDIO_MCK
S39
I2S0_LRCK
S40
I2S0_SDOUT
S41
I2S0_SDIN
S42
I2S0_CK
S43
ESPI_ALERT0#
S44
ESPI_ALERT1#
S45
MDIO_CLK
S46
MDIO_DAT
S47
GND
S48
I2C_GP_CK
Page 51
Module Termination Type/Tolerance
- GPIO / 3.3V
- GBE MDI
- GBE MDI
- GPIO / 3.3V
- GBE MDI
- GBE MDI
- -
- GBE MDI
- GBE MDI
- Analog / 3.3V
- -
- -
- GPIO / 3.3V
- -
- -
- -
- USB / 3.3V
- USB / 3.3V
- -
- I2S / 1.8V
- I2S / 1.8V
- I2S/ 1.8V
- I2S / 1.8V
- I2S / 1.8V
- -
- -
- -
- -
- -
PU-2.2K I2C / 1.8V
copyright © 2023 ADLINK Technology Inc.
Controller Controller Pin Name
LAN7800/VSX LED1
LAN7800/VSX TR1P
LAN7800/VSX TR1N
LAN7800/VSX LED0
LAN7800/VSX TR2P
LAN7800/VSX TR2N
- -
LAN7800/VSX TR3P
LAN7800/VSX TR3N
- -
- -
- -
LAN7800/VSX LED2
- -
- -
- -
USB5807C/KD USB2DN_DP5
USB5807C/KD USB2DN_DM5
- -
MT8395 I2SO1_MCK
MT8395 I2SO1_WS
MT8395 I2SO1_D0
MT8395 I2SIN_D0
MT8395 I2SO1_BCK
- -
- -
- -
- -
- -
MT8395 SCL3
SGET SMARC Rev 2.1
I/O Mux default
ALT1
ALT1
ALT1
ALT1
ALT1
ALT1
