4.2 Signal Terminology Descriptions

Meaning of the terms used for signal description tables. Signals described in the specification but not supported on the LEC-iMX8M Plus are marked with
strikethrough STRIKETHROUGH
Term Description
I Input to the Module
O Output from the Module
I/O Bi-directional input/output
OD Open drain
PU PU (pull-up) resistor
PD PD (pull-down) resistor
CMOS Logic input or output
GBE MDI Differential analogue signalling for gigabit media dependent interface
DP Low voltage differential signal for DisplayPort interface
D-PHY Low voltage differential signal for MIPI CSI-2 cameras and DSI displays
M-PHY Low voltage differential signal for MIPI CSI-3 cameras
LVDS Low voltage differential signal for LCD displays
PCIE Low voltage differential signal for PCIe
SATA Low voltage differential signal for SATA
TMDS HDMI Transition minimized differential signal for HDMI displays
USB DC coupled differential signalling for traditional (non-Superspeed) USB signals
USB SS Differential signal for SuperSpeed USB signals
USB VBUS 5V 5V tolerant input for USB VBUS detection
VDD_IN Main power source from Carrier to Module
3.3V 3.3V power domain: Active while CARRIER_PWRON is high and CARRIER_SBY# is NOT active (i.e. both signals are high)
1.8V 1.8V power domain: Active while CARRIER_PWRON is high and CARRIER_SBY# is NOT active (i.e. both signals are high)
3.3Vsb 3.3V standby power domain: Active while CARRIER_PWRON is high (regardless of CARRIER_SBY#)
1.8Vsb 1.8V standby power domain: Active while CARRIER_PWRON is high (regardless of CARRIER_SBY#)
Sleep Module is in its lowest power state
Runtime Module is full on. CARRIER_PWRON is high and CARRIER_SBY# is NOT active (i.e. both signals are high)
Standby Module is in standby state or higher
