LEC-MTK-i1200 User's Guide
SMARC
Signal Name
P145
CAN1_TX
P146
CAN1_RX
P147
VDD_IN
P148
VDD_IN
P149
VDD_IN
P150
VDD_IN
P151
VDD_IN
P152
VDD_IN
P153
VDD_IN
P154
VDD_IN
P155
VDD_IN
P156
VDD_IN
S1
CSI1_TX+ / I2C_CAM1_CK
S2
CSI1_TX- / I2C_CAM1_DAT
S3
GND
S4
RSVD
S5
CSI0_TX- / I2C_CAM0_CK
S6
CAM_MCK
S7
CSI0_TX+ / I2C_CAM0_DAT
S8
CSI0_CK+
S9
CSI0_CK-
S10
GND
S11
CSI0_RX0+
S12
CSI0_RX0-
S13
GND
S14
CSI0_RX1+
S15
CSI0_RX1-
S16
GND
S17
GBE1_MDI0+
S18
GBE1_MDI0-
Page 50
Module Termination Type/Tolerance
- -
- -
- -
- -
- -
- -
- -
- -
- -
- -
- -
- -
PU-2k2 I2C / 1.8V
PU-2k2 I2C / 1.8V
- -
- -
- I2C / 1.8V
- CAM / 1.8V
- I2C / 1.8V
- CSI
- CSI
- -
- CSI
- CSI
- -
- CSI
- CSI
- -
- GBE MDI
- GBE MDI
copyright © 2023 ADLINK Technology Inc.
Controller Controller Pin Name
- -
- -
From Carrier board -
From Carrier board -
From Carrier board -
From Carrier board -
From Carrier board -
From Carrier board -
From Carrier board -
From Carrier board -
From Carrier board -
From Carrier board -
Camera Module
Camera Module
- -
- -
MT8395 SCL0
MT8395 CMMCLK0
MT8395 SDA0
MT8395 CSI1A_L1P_T0C
MT8395 CSI1A_L1N_T1A
- -
MT8395 CSI1A_L0P_T0A
MT8395 CSI1A_L0N_T0B
- -
MT8395 CSI1A_L2P_T1B
MT8395 CSI1A_L2N_T1C
- -
LAN7800/VSX TR0P
LAN7800/VSX TR0N
SGET SMARC Rev 2.1
I/O Mux default
ALT1
ALT1
ALT1
