ADLINK Technology SMARC LEC-MTK-I1200 User Manual page 46

LEC-MTK-i1200 User's Guide
SMARC
Signal Name
P27
GBE0_MDI1+
P28
GBE0_CTREF
P29 GBE0_MDI0-
P30
GBE0_MDI0+
P31
SPI0_CS1#
P32
GND
P33
SDIO_WP
P34
SDIO_CMD
P35
SDIO_CD#
P36
SDIO_CK
P37
SDIO_PWR_EN
P38
GND
P39
SDIO_D0
P40
SDIO_D1
P41
SDIO_D2
P42
SDIO_D3
P43
SPI0_CS0#
P44
SPI0_CK
P45
SPI0_DIN
P46
SPI0_DO
P47
GND
P48
SATA_TX+
P49
SATA_TX-
P50
GND
P51
SATA_RX+
P52
SATA_RX-
P53
GND
P54
ESPI_CS0# / SPI1_CS0#
P55
ESPI_CS1# / SPI1_CS1#
P56
ESPI_CK / SPI1_CK
Page 46
Module Termination Type/Tolerance
- GBE MDI
- Analog / 3.3V
- GBE MDI
- GBE MDI
- -
- -
- SD / 1.8
- SD / 1.8/3.3V
- SD / 1.8
- SD / 1.8/3.3V
- GPIO / 3.3V
- -
- SD / 1.8/3.3V
- SD / 1.8/3.3V
- SD / 1.8/3.3V
- SD / 1.8/3.3V
- SPI / 1.8V
- SPI / 1.8V
- SPI / 1.8V
- SPI / 1.8V
- -
- -
- -
- -
- -
- -
- -
- SPI / 1.8V
- -
- SPI / 1.8V
copyright © 2023 ADLINK Technology Inc.
Controller Controller Pin Name
DP83867IRRGZR TD_P_B
- -
DP83867IRRGZR TD_M_A
DP83867IRRGZR TD_P_A
- -
- -
MT8395 GPIO
MT8395 MSDC1_CMD
MT8395 GPIO
MT8395 MSDC1_CLK
MT8395 GPIO
- -
MT8395 MSDC1_DAT0
MT8395 MSDC1_DAT1
MT8395 MSDC1_DAT2
MT8395 MSDC1_DAT3
MT8395 SPIM1_CSB
MT8395 SPIM1_CLK
MT8395 SPIM1_MI
MT8395 SPIM1_MO
- -
- -
- -
- -
- -
- -
- -
MT8395 SPIM2_CSB
- -
MT8395 SPIM2_CLK
SGET SMARC Rev 2.1
I/O Mux default
ALT0
ALT1
ALT0
ALT1
ALT0
ALT1
ALT1
ALT1
ALT1
ALT1
ALT1
ALT1
ALT1
ALT1
ALT1
