LEC-MTK-i1200 User's Guide

4.3 Signal Description by Function

4.3.1 Primary Display Interface
HDMI, eDP, DP and DSI are all supported on this module
Pin # LVDS Name MIPI DSI Name
S125 LVDS0_0+ DSI0_D0+
S126 LVDS0_0- DSI0_D0-
S128 LVDS0_1+ DSI0_D1+
S129 LVDS0_1 DSI0_D1-
S131 LVDS0_2+ DSI0_D2+
S132 LVDS0_2- DSI0_D2-
S137 LVDS0_3+ DSI0_D3+
S138 LVDS0_3- DSI0_D3-
S134 LVDS0_CK+ DSI0_CLK+
S135 LVDS0_CK- DSI0_CLK-
S133 LCD0_VDD_EN LCD0_VDD_EN
S127 LCD0_BKLT_EN LCD0_BKLT_EN
S141 LCD0_BKLT_PWM LCD0_BKLT_PWM
S144 DSI0_TE
Page 23
eDP Name
eDP0_TX0+
eDP0_TX0-
eDP0_TX1+
eDP0_TX1-
eDP0_TX2+
eDP0_TX2-
eDP0_TX3+
eDP0_TX3-
eDP0_AUX+
eDP0_AUX-
LCD0_VDD_EN
LCD0_BKLT_EN
LCD0_BKLT_PWM
eDP0_HPD
copyright © 2023 ADLINK Technology Inc.
Pin # LVDS Name
S111 LVDS1_0+
S112 LVDS1_0-
S114 LVDS1_1+
S115 LVDS1_1
S117 LVDS1_2+
S118 LVDS1_2-
S120 LVDS1_3+
S121 LVDS1_3-
S108 LVDS1_CK+
S109 LVDS1_CK-
S116 LCD1_VDD_EN
S107 LCD1_BKLT_EN
S122 LCD1_BKLT_PWM
S113
S139 I2C_LCD_CK
S140 I2C_LCD_DAT
SGET SMARC Rev 2.1
MIPI DSI Name eDP Name
DSI1_D0+ eDP1_TX0+
DSI1_D0- eDP1_TX0-
DSI1_D1+ eDP1_TX1+
DSI1_D1- eDP1_TX1-
DSI1_D2+ eDP1_TX2+
DSI1_D2- eDP1_TX2-
DSI1_D3+ eDP1_TX3+
DSI1_D3- eDP1_TX3-
DSI1_CLK+ eDP1_AUX+
DSI1_CLK- eDP1_AUX-
LCD1_VDD_EN LCD1_VDD_EN
LCD1_BKLT_EN LCD1_BKLT_EN
LCD1_BKLT_PWM LCD1_BKLT_PWM
DSI1_TE eDP1_HPD
I2C_LCD_CK I2C_LCD_CK
I2C_LCD_DAT I2C_LCD_DAT
