4.4.13 Power
Name Pin #
VDD_IN P147, P148, P149,
P150, P151, P152,
P153, P154, P155,
P156
GND P2, P9, P12, P15, P18,
P32, P38, P47, P50,
P53, P59, P68, P79,
P82, P85, P88, P91,
P94, P97, P100, P103,
P120, P133, P142, S3,
S10, S16, S25, S34,
S47, S61, S64, S67,
S70, S73, S80, S83,
S86, S89, S92, S101,
S110, S119, S124,
S130, S136, S143, S158
VDD_RTC S147
Page 44
Description I/O Type
Module power input voltage P Not defined within Signal
4.75 min to 5.25V max Terminology Descriptions.
Should we define a specific
rail?
Module signal and power return, P Not defined within Signal
and GND reference Terminolgy Descriptions.
Should we define a specific
rail?
Low current RTC circuit backup P Not defined within Signal
power – 3.0V nominal. May be Terminolgy Descriptions.
sourced from a Carrier based Should we define a specific
Lithium cell or Super Cap. rail?
copyright © 2023 ADLINK Technology Inc.
SGET SMARC Rev 2.1
Power Rail / PU / Comments
Tolerance PD
5V +/- 5%
Ground
[2 to 3.25] / 3.25V
