LEC-MTK-i1200 User's Guide
SGET SMARC Rev 2.1
2.2.2 Display Interfaces
MIPI DSI
2x MIPI DSI 4 lane, compliant with MIPI-DSI standard v1.2, max. resolution 4K p60
eDP
1x 4lane eDP port
HDMI
HDMI 2.0b , Supports a maximum display resolution of 4K p60
DP
Displayport 1.4, 4K p60
2.3 Camera
Supports CSI0 2-lane and CSI1 4-lane MIPI CSI2 camera input over MXM connector.
CSI2 on module feature connector (4 lanes)
2.4 Audio
Supports on-carrier I
2
S codec
Page 12
copyright © 2023 ADLINK Technology Inc.
